Wiring & Installation Guides
Step-by-step visual guides to install and wire every ACXA product. Includes wiring diagrams, photos, and demo videos.
DSP-C Touch Screen Controller
Replace your Pailung machine's original touch screen with the DSP-C controller. Compatible with Schneider ATV312 and Altivar 31 drives.
496YC Winding Counter
Install the 496YC counter on your cone or tube winding machine. Wiring guide for sensor, motor relay, and GREEN plug connections.
CH270 Knitting Controller
Replace your existing circular knitting machine panel with the CH270. Standard 270x210mm size fits most medium-format machines.
KMC21 Controller
Wiring guide for the KMC21 controller, compatible with Mayer & CIE, Terrot, and Fukuhara machines.
Digital Panel Meters
Wiring guides for ACXA digital panel meters - counters, batch counters, totalizers, RPM indicators, and temperature controllers. Standard 96x96mm and 72x72mm DIN sizes.
